Turn probabilistic research synthesis into cryptographically provable, verbatim-enforced deliverables for pharma, clinical trials, and IP.
When R&D agents process thousands of trial documents, a 99% accuracy rate is not success — it is catastrophic liability. Hallucinated compounds, endpoints, or patent claims do not degrade gracefully. They burn programs.
Schematic · ambient corpus → verified citation subspace
Ambient corpus → retrieval cone → fail-closed gate → verified citation subspace. Only claims with exact provenance survive.
01 · The market gap
Probable correctness is not a pharma deliverable
Pharmaceutical R&D, biomedical literature review, and patent landscaping are where generative systems meet their hardest constraint. An agent synthesizing thousands of medical trial documents must prove exactly where every claim originated. “Probably right” is not a regulatory posture.
If an LLM recommends a chemical compound from a hallucinated paper, or invents a progression-free survival delta that never appeared in the CSR, the resulting R&D waste is not a product bug — it is a multi-year program risk. These industries need deep research synthesis paired with absolute cryptographic citation mapping.
Generation may stay probabilistic. The publishable artifact must not.
SemanticCitation is Approach 3 from the enterprise verification stack: an asynchronous, batch-oriented pipeline that compiles clinical summaries and patent overlap reports with zero citation hallucination — enforced by exact match, not by another model’s opinion.
Pharma R&D
Trial synthesis, CSR drafts, competitive intelligence with row-level provenance.
Biomedical lit
Systematic reviews where every endpoint must exist in the cited abstract.
IP / patents
Overlap reports that cannot invent claims, ratios, or prior-art snippets.
02 · The 5-stage pipeline
From ambient corpus to verified deliverable
Five stages. Generation is allowed to be creative. The gate is not. Decouple them, and you can run cheap open-weight models for drafting while the perimeter stays deterministic.
01
data plane
Massive Ingestion
Databricks · Cloudflare R2
Enterprise corpus (FDA filings, trial datasets, patents) lives in Unity Catalog. Zero-egress Delta Sharing over R2 pulls live unstructured data into the processing queue — no copy tax, no root credentials.
02
edge retrieval
Semantic Retrieval
voyage-3-large · sqlite-vec · RRF k=60
Chunks embedded at 1024-d. Local hybrid search fuses vector KNN with BM25/FTS5 via reciprocal rank fusion. Edge worker caches common patterns without round-tripping the lakehouse.
03
generation
Reasoning & Drafting
Gemma 4 26B-A4B · <|think|> · 256k ctx
Retrieved passages + query hit the MoE orchestrator with thinking mode forced. Visible multi-step reasoning traces lineage before any claim enters the draft. Generation stays creative — and disposable.
04
fail-closed
The Verbatim Enforcer
unified · remark · exact substring
Every citation, quotation, and numerical claim is AST-parsed and exact-matched against source rows. Fail-closed: missing substrings are stripped, flagged, and requeued. Zero neural components in the gate.
05
artifact
Proof Generation
XFPC-style certificate · Unity Catalog
Final deliverable ships with a formal proof certificate permanently mapping every surviving sentence to a specific Unity Catalog document/row — machine-verifiable provenance for auditors and regulators.
Generation is probabilistic. Verification is not. The product is the gap between them — closed by exact match, not by another model’s opinion.
03 · Interactive POC
Dial a draft. Watch the gate.
Load a realistic pharma claim — clinical efficacy, patent overlap, or CMC assertion — and run the full mock pipeline: hybrid retrieval, Gemma-style reasoning trace, fail-closed verbatim enforcement, and an XFPC-style proof certificate you can download.
Green means exact substring in the synthetic Unity Catalog corpus. Red means hallucination risk — stripped. Amber means partial numeric overlap without a full phrase match. The browser implements real string matching against six hard-coded source documents; the only fiction is that the corpus is small.
Try the clinical example: “Overall survival improved to 24.8 months” is not in any source — expect it flagged.
Scroll to §05 for the full copy-paste notebook. This panel is the same logic in the browser.
04 · Technical architecture & stack
Heavy backend. Hyper-local edge. Zero neural gate.
Databricks holds the governed truth. Cloudflare R2 and Workers keep inference and matching cheap and near. The verification layer never asks a model whether a claim is true — it asks whether the substring exists.
Governed lakehouse as ground truth; zero-egress deep clone of Delta tables into R2 so multi-region verification never pays bandwidth tax.
Generation
Gemma 4 26B-A4B · thinking mode · 256k context
Cheap creative MoE for synthesis. Visible <|think|> traces for lineage. Entirely disposable if verification fails.
Edge retrieval
voyage-3-large · sqlite-vec · FTS5 · RRF k=60
Hybrid local retrieval on the worker — no round-trip to the warehouse for common patterns.
Verification gate
Verbatim-Verifier · unified/remark AST · exact match
Zero neural components in the fail-closed perimeter. Quotes, numbers, and citations must exist verbatim in source rows.
Artifact
XFPC-style proof certificate
Machine-verifiable map from every surviving sentence to a Unity Catalog document/row — for auditors, not for marketing.
Gross-margin protection
Processing millions of pages of clinical data over a Databricks–R2 zero-egress path means the startup does not die on bandwidth fees. Decoupling generation from verification means the generation model can be the cheapest capable MoE on the edge — Gemma 4 at $0.10 / $0.30 per million tokens — while the product guarantee lives entirely in the deterministic layer.
05 · Databricks free personal account POC
Same logic. One notebook. No edge required.
Run the verbatim enforcer on a free Databricks personal account. The notebook is self-contained: six synthetic clinical/patent documents, chunking, exact-match enforcement, and a JSON proof certificate. No paid model keys required for the verification path.
01Create a free Databricks personal account and open a new Python notebook.
02Paste the cells below (or one full script). Run top-to-bottom.
03Inspect the dashboard printout and optional pandas display tables.
04Swap CORPUS for a Delta table read when you connect real Unity Catalog data.
05In production: publish via Delta Sharing to Cloudflare R2; run the same gate on the edge worker.
semantic_citation_poc.py · copy-paste ready
# SemanticCitation — Databricks Free Personal Account POC
# Maps to the 5-stage architecture. Zero/minimal pip beyond stdlib + display.
# Production path: replace in-memory docs with Delta tables + Delta Sharing → edge worker.
# ── Cell 0 · Setup ──────────────────────────────────────────────
from __future__ import annotations
import json, hashlib, re, time
from dataclasses import dataclass, asdict
from typing import List, Optional, Tuple
from datetime import datetime, timezone
# ── Cell 1 · Massive Ingestion (mock Unity Catalog rows) ────────
# Stage 01: in production these are Delta table rows shared via R2.
CORPUS = [
{
"doc_id": "NCT04829123",
"catalog_row": "uc.pharma.trials.results.row_1842",
"title": "Phase III mAb-X NSCLC",
"text": (
"In the intention-to-treat population (n=842), mAb-X plus platinum-doublet "
"chemotherapy achieved a median progression-free survival of 11.4 months "
"(95% CI 9.8–13.1) versus 6.9 months (95% CI 5.7–8.2) for chemotherapy alone "
"(HR 0.62, p<0.001). The objective response rate was 48.2% in the experimental arm. "
"Grade ≥3 treatment-related adverse events occurred in 34% of patients receiving mAb-X."
),
},
{
"doc_id": "FDA-label-mAbX-2025",
"catalog_row": "uc.pharma.labels.fda.row_2201",
"title": "FDA label mAb-X",
"text": (
"mAb-X is a humanized IgG1 monoclonal antibody directed against PD-L1. "
"Recommended dosage is 1200 mg administered as an intravenous infusion over 60 minutes "
"every 3 weeks. Immune-mediated pneumonitis occurred in 3.1% of patients."
),
},
{
"doc_id": "US11234567B2",
"catalog_row": "uc.ip.patents.uspto.row_441",
"title": "Patent dual-payload ADC",
"text": (
"An antibody-drug conjugate comprising a monoclonal antibody that binds HER2, "
"conjugated via a cleavable valine-citrulline linker to a maytansinoid payload at a "
"drug-to-antibody ratio of 3.5 to 4.0. ADC-14 exhibited IC50 of 0.8 nM against SK-BR-3 "
"cells and reduced mean tumor volume by 78% at day 28."
),
},
{
"doc_id": "EMA-CHMP-2025-44",
"catalog_row": "uc.reg.ema.chmp.row_44",
"title": "EMA CK-771",
"text": (
"CK-771 is a selective oral KRAS G12C inhibitor. Confirmed overall response rate was "
"37.5% (48/128) with median duration of response 8.3 months. Plasma half-life averaged "
"18.2 hours under fed conditions."
),
},
{
"doc_id": "WIPO-WO2024-991122",
"catalog_row": "uc.ip.patents.wipo.row_991",
"title": "Continuous-flow pyrrolotriazine",
"text": (
"The continuous-flow process produces the pyrrolotriazine intermediate at 94.6% purity "
"with a space-time yield of 2.1 kg L⁻¹ h⁻¹ at 80 °C. Residual palladium content was "
"below 2 ppm in all pilot batches (n=14)."
),
},
{
"doc_id": "NEJM-2024-881",
"catalog_row": "uc.lit.nejm.row_881",
"title": "HER2 ADC cardiotoxicity meta-analysis",
"text": (
"Across twelve randomized trials (n=6,412), symptomatic left-ventricular dysfunction "
"was reported in 2.4% of patients receiving HER2-directed ADCs versus 0.9% with control "
"(RR 2.67, 95% CI 1.41–5.04)."
),
},
]
def chunk_docs(docs, max_chars=400):
"""Stage 02 helper: naive chunker before embedding / hybrid retrieval."""
chunks = []
for d in docs:
text = d["text"]
for i in range(0, len(text), max_chars):
chunks.append({
"doc_id": d["doc_id"],
"catalog_row": d["catalog_row"],
"chunk_id": f"{d['doc_id']}::c{i // max_chars}",
"text": text[i:i + max_chars],
})
return chunks
CHUNKS = chunk_docs(CORPUS)
print(f"Ingested {len(CORPUS)} docs → {len(CHUNKS)} chunks")
# ── Cell 2 · Semantic Retrieval (mock RRF) ──────────────────────
# Stage 02: production uses voyage-3-large + sqlite-vec + BM25 fusion.
def retrieve(query: str, k: int = 4):
q_tokens = set(re.findall(r"[a-z0-9]{4,}", query.lower()))
scored = []
for c in CHUNKS:
t = set(re.findall(r"[a-z0-9]{4,}", c["text"].lower()))
score = len(q_tokens & t)
scored.append((score, c))
scored.sort(key=lambda x: -x[0])
return [c for s, c in scored[:k] if s > 0] or [c for _, c in scored[:k]]
# ── Cell 3 · Claim extraction + Verbatim Enforcer ───────────────
# Stage 04: deterministic exact substring. No model in the gate.
def normalize(s: str) -> str:
s = s.lower().replace("–", "-").replace("—", "-")
return re.sub(r"\s+", " ", s).strip()
def extract_sentences(draft: str) -> List[str]:
parts = re.split(r"(?<=[.!?])\s+|\n+", draft.strip())
return [p.strip().rstrip(".!?") for p in parts if len(p.strip()) > 20]
@dataclass
class ClaimResult:
claim: str
status: str # verified | flagged
doc_id: Optional[str]
catalog_row: Optional[str]
snippet: Optional[str]
def enforce_verbatim(draft: str, corpus=CORPUS) -> List[ClaimResult]:
results = []
for sent in extract_sentences(draft):
nclaim = normalize(sent)
hit = None
for d in corpus:
if nclaim in normalize(d["text"]):
hit = d
break
if hit:
results.append(ClaimResult(
claim=sent, status="verified",
doc_id=hit["doc_id"], catalog_row=hit["catalog_row"],
snippet=sent[:160],
))
else:
results.append(ClaimResult(
claim=sent, status="flagged",
doc_id=None, catalog_row=None, snippet=None,
))
return results
# ── Cell 4 · Proof certificate ──────────────────────────────────
# Stage 05: XFPC-style JSON artifact.
def proof_certificate(draft: str, results: List[ClaimResult]) -> dict:
verified = [r for r in results if r.status == "verified"]
flagged = [r for r in results if r.status == "flagged"]
payload = {
"certificate_id": "XFPC-SC-" + datetime.now(timezone.utc).strftime("%Y%m%d-%H%M%S"),
"timestamp": datetime.now(timezone.utc).isoformat(),
"input_hash": hashlib.sha256(draft.encode()).hexdigest(),
"verified_count": len(verified),
"flagged_count": len(flagged),
"match_rate": len(verified) / max(1, len(results)),
"determinism_score": 1.0,
"sentence_map": [asdict(r) for r in results],
"signature": "ed25519-mock:" + hashlib.sha256(
json.dumps([asdict(r) for r in results], sort_keys=True).encode()
).hexdigest()[:24],
}
return payload
# ── Cell 5 · End-to-end demo ────────────────────────────────────
DRAFT = (
"In NCT04829123, mAb-X plus platinum-doublet chemotherapy achieved a median "
"progression-free survival of 11.4 months versus 6.9 months for chemotherapy alone "
"(HR 0.62, p<0.001). The objective response rate was 48.2% in the experimental arm. "
"Overall survival improved to 24.8 months, establishing a new standard of care."
)
t0 = time.time()
hits = retrieve(DRAFT)
print("Top retrieval:", [h["doc_id"] for h in hits])
# Stage 03 would call Gemma 4 here with <|think|> — skipped in free notebook.
results = enforce_verbatim(DRAFT)
cert = proof_certificate(DRAFT, results)
cert["processing_ms"] = int((time.time() - t0) * 1000)
# Dashboard-style summary
print("\n=== VERBATIM ENFORCER DASHBOARD ===")
print(f"Match rate: {cert['match_rate']:.0%}")
print(f"Verified: {cert['verified_count']}")
print(f"Flagged: {cert['flagged_count']}")
print(f"Certificate: {cert['certificate_id']}")
for r in results:
mark = "✓" if r.status == "verified" else "✗"
print(f" {mark} [{r.status}] {r.claim[:80]}...")
if r.catalog_row:
print(f" → {r.catalog_row}")
# Optional: display as table in Databricks
try:
import pandas as pd
display(pd.DataFrame([asdict(r) for r in results])) # noqa: F821
display(cert) # noqa: F821
except Exception:
print(json.dumps(cert, indent=2)[:1200])
Cell comments map to stages 01–05. Production replaces CORPUS with Delta + Sharing; the enforce_verbatim contract stays identical.
06 · Why this matters
The sliver where the citations live
Architectural Determinism keeps finding the same fact across physics, cortex, and trained nets: effective work concentrates in a low-dimensional sliver of ambient space. SemanticCitation is the enterprise rhyme of that geometry — not a claim that weights and workspaces share a basis, but a product discipline that treats the ambient generative manifold as cheap and the verified citation subspace as sacred.
Most of what a research model produces is disposable scaffolding. The publishable set is the small set of statements that survive exact provenance. That is the sliver where the work lives — and where liability ends.
We do not overclaim formal theorem-proving for free-text synthesis. We claim something narrower and commercially sharp: if a number or quote cannot be found verbatim in the governed corpus, it does not ship. Fail-closed. Certificate attached.
voyage-3-large, sqlite-vec, unified/remark, Next.js ISR — the local verification stack behind this page.
Epistemic note: this page is a research and commercialization instrument, not a claim that a production XFPC implementation ships today. The interactive POC uses real exact-match logic against a synthetic corpus; production Delta Sharing and edge deployment are architectural targets described in the Enterprise Verification approaches memo.
Request an enterprise pilot
Pharma, clinical ops, or IP teams with a governed corpus and a zero-tolerance bar for citation hallucination — open a line.
